ZKTeco EL-854N38I-S7 4MP Lite Series Eyeball Camera
KSh 18,000.00
ZKTeco EL-854N38I-S7 4MP Lite Series Eyeball Camera
| Sensor | 4MP 1/3” CMOS |
| Lens | Motorized, 2.8–12mm |
| IR Range | 50 m |
| Resolution | 4MP / 3MP / 1080P / 1.3MP / 720P |
| Housing | IP67 |
| Power | PoE / 12V DC |
ZKTeco EL-854N38I-S7 4MP Lite Series Eyeball Camera
The EL-854N38I-S7 is a 4MP motorized eyeball camera from ZKTeco’s Lite Series, designed for high-resolution video monitoring in diverse scenarios. With built-in P2P cloud functionality, it allows convenient remote real-time viewing and flexible deployment. Ideal for users seeking cost-efficient, high-quality surveillance with ease of installation.
Key Features
-
4MP 1/3” CMOS Sensor
Crystal-clear video with excellent low-light performance. -
Motorized Lens (2.8–12mm)
Flexible field of view (37°–98°) and optical zoom support. -
IR Night Vision
2 IR LEDs provide visibility up to 50 m in complete darkness. -
Video Compression & Streaming
Supports H.265/H.264, multi-streaming up to 4MP@20fps. -
Advanced Image Features
DWDR, 2D/3D noise reduction, mirror/flip, corridor mode, HLC, BLC. -
Durable & Flexible Installation
Compact IP67-rated design with PoE support for simplified deployment.
Specifications
| Feature | Specification |
|---|---|
| Model | EL-854N38I-S7 |
| Image Sensor | 1/3” CMOS |
| Effective Pixels | 2560 × 1440 |
| Lens Type | Motorized, 2.8–12mm, F1.2–2.2 |
| FOV | 37°–98° |
| Optical Zoom | Supported |
| Min. Illumination | Color: 0.01Lux@F1.2–2.2, B/W: 0.001Lux@F1.2–2.2(IR ON) |
| IR Distance | 50 m |
| Compression | H.265 / H.264 |
| Resolution | 4MP / 3MP / 1080P / 1.3MP / 720P |
| Multi-Streaming | Main: 4MP@20fps, Sub: D1@25fps, Third: N/A |
| Motion Detection | Supported |
| Privacy Mask | 4 areas |
| WDR / DNR | DWDR / 2D & 3D DNR |
| Day/Night | Supported |
| Max Online Users | 3 |
| Network Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IPv4, SSL/TLS |
| Interoperability | ONVIF Profile S, SDK, API |
| Web Browser | IE / Firefox / Chrome / Safari |
| Mobile App | AntarView Pro |
| VMS | AntarVis 2.0, ZKBioSecurity IVS, ZKBioAccess IVS |
| Interface | 1 × RJ-45 (10/100Mbps), 1 × Audio In/Out |
| Power Supply | PoE (IEEE802.3af) / DC 12V±10% |
| Power Consumption | <3 W |
| Ingress Protection | IP67 |
| Dimensions (L×W×H) | Φ111.6 × 105 mm |
| Operating Temp | –30°C ~ +60°C |
| Humidity | 10% ~ 90% |
| Net/Gross Weight | 0.40 / 0.64 kg |
Why Choose EL-854N38I-S7
-
High-resolution 4MP monitoring for detailed surveillance
-
Cost-efficient Lite Series solution
-
Compact IP67-rated design with PoE support
-
Flexible multi-streaming and video compression
