ZKTeco PE16-180 PoE Switch

KSh 17,000.00

ZKTeco PE16-180 PoE Switch


Model	PE16-180
Ports	16× PoE (10/100 Mbps), 2× Combo Uplink
PoE Budget	30 W/port, 250 W total
Switching	64 Gbps, 4 MB buffer
Security	VLAN, QoS, ACL, SSH, DHCP Snooping
Size	440 × 290 × 44.5 mm

Category: Zkteco

Description
Reviews (0)

ZKTeco PE16-180 PoE Switch

The PE16-180 is a high-capacity managed PoE switch engineered for enterprise-grade video surveillance, access control, and IoT deployments. With 16 PoE ports and 2 combo uplink ports, it delivers robust data and power over Ethernet with advanced management, security, and energy-saving features.

Key Features

16 PoE + 2 Combo Uplink Ports
Supports IEEE 802.3af/at with up to 30 W per port and a 250 W total PoE budget.
Advanced Switching Performance
Non-blocking 64 Gbps bandwidth and 5.36 Mpps forwarding ensure smooth data flow.
Enterprise-Level Management
VLANs, QoS, STP/RSTP/MSTP, LACP, DHCP snooping, ACLs, and port mirroring for secure, optimized networks.
Robust Protection & Reliability
CE/FCC/VCCI certifications, storm control, IP source guard, and a 100,000 h MTBF.
Energy-Efficient Design
IEEE 802.3az EEE technology minimizes power usage during low data traffic.

Specifications

Feature	Specification
Model	PE16-180
PoE Ports (1–16)	10/100 Mbps, 30 W max each
Uplink Ports (17–18)	10/100/1000 Mbps combo @100 m
PoE Budget	250 W total
Standards	IEEE 802.3af / 802.3at
Switching Bandwidth	64 Gbps (non-blocking)
Forwarding Rate	5.36 Mpps
Buffer Memory	4 MB
MAC Table	16 K
Power Input	AC 220 V, 50/60 Hz
PoE Pin Assignment	1,2 (+) / 3,6 (−) (default); 4,5 (+), 7,8 (−) optional
Operating Temp.	−20 °C ~ +50 °C
Humidity	10%–90% (non-condensing)
Safety Standards	CE, FCC Part 15 Class B, VCCI Class B
VLAN Support	802.1Q (4K VLANs), port-based VLAN
QoS	Priority queues, scheduling, rate limiting
Security	SSH, SSL/HTTPS, ARP inspection, port security, DHCP snooping, storm control
Management	Web, firmware upgrade, port mirroring
Dimensions (L×W×H)	440 × 290 × 44.5 mm
MTBF	100,000 h
