ZKTeco ZKX10080 X-Ray Inspection System
KSh 2,900,000.00
ZKTeco ZKX10080 X-Ray Inspection System
| Model | ZKX10080 |
| Type | Dual-Energy X-Ray Scanner |
| Tunnel | 1000 × 800 mm |
| Conveyor | 0.2–0.4 m/s |
| Max Load | 200 kg |
| Power | 1 kVA |
ZKTeco ZKX10080 X-Ray Inspection System
The ZKX10080 is a professional dual-energy X-ray scanner designed for screening parcels, luggage, and cargo up to 100 × 80 cm. With a refined image algorithm and a high-quality generator, it delivers sharp, detailed scans that help operators quickly identify threats. A low conveyor height, foldable belt, and biometric operator login combine to create a secure, ergonomic, and cost-efficient solution for busy security checkpoints.
Key Features
Spacious Tunnel
Handles large baggage with its 1000 × 800 mm opening.Superior Image Quality
Dual-energy source with optimized algorithm provides clear scans for accurate threat detection.Biometric Operator Access
Enhances system security and eliminates password concerns.Foldable Conveyor Design
Reduces packing volume to lower transport costs.Easy Maintenance
Side-door design gives quick access for servicing and cleaning.
Specifications
| Category | Details |
|---|---|
| Model | ZKX10080 |
| Type | X-Ray Baggage & Parcel Inspection |
| Tunnel Size (W × H) | 1000 × 800 mm |
| Conveyor Speed | 0.2–0.4 m/s (adjustable) |
| Conveyor Height | 385 mm |
| Max Load | 200 kg (evenly distributed) |
| Penetration | 32 mm steel |
| Wire Resolution | 36 AWG |
| Film Safety | ASA/ISO 1600 |
| Radiation Leak | ≤0.2 μGy/h (5 cm from surface) |
| Tube Voltage | 80–160 kV (adjustable) |
| Tube Current | 0.3–1.0 mA |
| Cooling | Sealed oil bath / 100% |
| Noise | ≤53.8 dB(A) |
| Console Desk | 1320 × 900 × 1320 mm |
| Unit Dimensions | 2984 × 1405 × 1666 mm |
| Package Dimensions | 2200 × 1500 × 1750 mm |
| Weight | 1050 kg + 135 kg (console) |
| Power Consumption | 1 kVA |
| Display | Dual 21.5″ LED monitors |
| Software Support | ZKBio SIS |
| Functions | High-density alert, explosive/drug detect, TIP, luggage counter, user mgmt, training |
Why Choose ZKX10080
Large tunnel ideal for parcels, luggage, and medium cargo
Crisp dual-energy images with advanced detection aids
Biometric access ensures operator security
Foldable belt minimizes shipping volume and costs
Easy side-door service for fast maintenance
